Pyrolysis Plant

Product overview

Pyrolysis plant was last used to convert HDPE plastic waste into diesel/oil .

Only used for 3 months.

Was able to convert 1 tonne of HDPE into approx 750 litres of diesel/oil.

14-16hr startup, then once operating each batch takes approx 12 hrs. Each batch can do approx 10 tonne of HDPE waste which will produce approx 7500lt of diesel/oil.

 Reactor : Batch type rotary kiln
 Processing method : Pyrolysis + Catalytic reforming(Dewaxing) + Vacuum distillation
 Electricity specification : 380V 3-Phase 4-Wire 150A
 Input : Plastic waste (PET and PVC are not recommended)
 Output : Oil to be used as fuel (Flash point can be adjusted)
 Fuel : LPG or diesel for initial operating then using syngas coming out of the prolysis
 Space : 16,000mm(W) x 25,000mm(L) x 9,000mm(H)
 Volume of rotary kiln : 30㎥ (ø 2800 x 7000L

Pyrolysis is a thermal decomposition of materials at elevated temperatures in an inert
atmosphere such as a vacuum gas. Pyrolysis is most commoly applied to the treatment
of organic materials. In general, pyrolysis of organic substances produces volatile
products and leaves a solid residue enriched in carbon, char. However, it’s almost
impossible that only pyrolysis process produces useful oil as fuel. Eco Creation applies a
rotary kiln, which has been proved successful compared to other types of reactors, for
the pyrolysis process. On the top of that, Eco Creation developed a catalyst process and
a distillation process, which enables its’ customers make outstanding performances

Plant made in Korea 2018

Located in Monbulk Victoria.
